System

Main Processor: Dual-core embedded processor

Operating System Embedded LINUX

Audio and Video:

IP Camera Input 16 Channel

Two-way Talk 1 Channel Input, 1 Channel Output, RCA

Display:

Interface 1 HDMI, 1 VGA

Resolution HDMI: 1920×1080, 1280×1024, 1280×720, 1024×768

VGA: 1920×1080, 1280×1024, 1280×720, 1024×768

Decoding Capacity 1ch@8MP 30fps, 4ch@1080P 30fps

Multi-screen Display 1/4/8/9/16

OSD Camera title, Time, Camera lock, Motion detection, Recording

Recording:

Compression H.265+/H.264+

Resolution 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.

Record Rate 80Mbps

Bit Rate 16Kbps ~ 20Mbps Per Channel

Record Mode Manual, Schedule(Regular(Continuous), MD, Stop

Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection and Alarm:

Trigger Events Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips

Video Detection Motion Detection, MD Zones: 396 (22 × 18),

and Tampering

Alarm input N/A

Relay Output N/A

Playback and Backup:

Sync Playback 1/4/9/16

Search Mode Time /Date, MD and Exact Search

(accurate to second)

Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom

Backup Mode: USB Device/Network
