mage Sensor 1/2.7″ CMOS

Effective Pixels 2560(H)×1440(V), 4MP

Scanning System Progressive

Electronic Shutter Speed PAL: 1/25~1/100000s

NTSC: 1/30~1/100000s

Minimum Illumination 0.03Lux/F2.0, 30IRE, 0Lux IR on

S/N Ratio More than 65dB

IR Distance Up to 20m (66feet)

IR On/Off Control Auto / Manual

IR LEDs 12

Lens

Lens Type Fixed lens / Fixed iris

Mount Type Board-in

Focal Length 3.6mm (2.8mm, 6mm Optional)

Max Aperture F2.0

Angle of View H: 76.4° (97°/48.6°)

V: 41.6° (52°/27.9°)

Focus Control N/A

Close Focus Distance 1400mm (800mm/2500mm)

55.1” (31.5”/98.4”)

Video

Resolution 4MP (2560×1440)

Frame Rate 25/30fps@4MP, 25/30fps@1080P

Video Output 1-channel BNC high definition video output / CVBS video output (Can switch)

Day/Night Auto (ICR) / Manual

OSD Menu Multi-language

BLC Mode BLC / HLC / DWDR

WDR DWDR

Gain Control AGC

Noise Reduction 2D

White Balance Auto / Manual

Smart IR Auto / Manual

Certifications

Certifications CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Interface N/A

Eelectrical

Power Supply 12V DC ±30%

Power Consumption Max 3.7W (12V DC, IR on)

Environmental

Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

* Start up should be done at above -40°C (-40°F)

Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH

Ingress Protection & Vandal Resistance IP67

Construction

Casing Plastic

Dimensions 154.3mm×69.8mm×69.8mm (6.07″×2.75″×2.75″)

Net Weight 0.15kg (0.33lb)

Gross Weight 0.21kg (0.46lb)
