Technical Specification

Camera

Image Sensor 1/2.7 inch CMOS

Effective Pixels 2560 (H) × 1440 (V), 4MP

Electronic Shutter Speed PAL:1/25s–1/100000s

NTSC:1/30s–1/100000s

Minimum Illumination 0.03Lux/F1.9, 30IRE, 0Lux IR on

IR Distance Distance up to 80 m (262.46 ft)

IR On/Off Control Auto; manual

IR LEDs Number 2

Pan/Tilt/Rotation Range

Pan: 0°–360°

Tilt: 0°–180°

Rotation: 0°–360°

Lens

Lens Type Fixed-focal

Mount Type M12

Focal Length 3.6 mm; 6 mm; 8 mm

Max. Aperture F2.0/F2.0/F1.9

Angle of View

3.6 mm: 89.5° × 76.4° × 41.6°

(diagonal × horizontal × vertical)

6 mm: 55.5° × 48.6° × 27.9°

(diagonal × horizontal × vertical)

8 mm: 41.9° × 36.3° × 20.3°

(diagonal × horizontal × vertical)

Video

Video Frame Rate

CVI: 4M@25fps/30fps; 1080P@25fps/30fps;

AHD: 4M@25fps/30fps;

TVI: 4M@25fps/30fps;

CVBS: 960H

Resolution 4MP (2560 × 1440); 1080P (1920 × 1080); 960H (960 ×

576/960 × 480)

Day/Night Auto switch by ICR

BLC BLC/HLC/DWDR

WDR DWDR

White Balance Auto; manual

Gain Control Auto; manual

Noise Reduction 2D NR

Smart IR Yes

Electronic Defog Yes

Mirror Off/On

Privacy Masking Off/On (8 area, rectangle)

Certifications

Certifications

CE (EN55032, EN55024, EN50130-4)

FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)

UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Video Port Video output choices of CVI/TVI/AHD/CVBS by one

BNC port

Power

Power Supply 12V±30% DC

Power Consumption Max 5.1W (12V DC, IR on)

Environment

Operating Temperature -40°C to +60°C (-40°F to +140°F);

<95% (non-condensation)

Storage Temperature -40°C to +60°C (-40°F to +140°F);

<95% (non-condensation)

Protection Grade IP67

Structure

Casing Metal front face + plastic main body + metal bracket

Dimensions 240.7 mm × 90.7 mm × 90.4 mm (9.48" × 3.57" × 3.56")

Net Weight 410 g (0.90 lb)

Gross Weight 616 g (1.36 lb)
