Camera

Image Sensor

2.0 megapixel progressive scan CMOS

Max. Resolution

1920 (H) × 1080 (V)

Min. Illumination

Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter Time

PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s

Day & Night

IR cut filter

Angle Adjustment

Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360°

Signal System

PAL/NTSC

Lens

Lens Type

2.8 mm, 3.6 mm fixed focal lens

Focal Length & FOV

103° (2.8 mm), 82.2° (3.6 mm)

Lens Mount

M12


Image Settings

Brightness, Contrast, Sharpness, Saturation, DNR, Mirror

Frame Rate

PAL: 1080p@25fps,NTSC: 1080p@30fps

Day/Night Mode

Auto/Color/BW (Black and White)

Image Enhancement

BLC

White Balance

Auto/Manual

White Light

Auto/Off

AGC

Low/middle/high

Supplement Detection(PIR)

PIR Range

Angle: 110°, Range:11 m

Interface

Video Output

TVI only

Alarm

Yes

General

Material

Metal

Dimension

68 mm × 70 mm × 179.8 mm ( 2.68" × 2.76" × 7.08" )

Weight

Approx. 345 g (0.76 lb.)

Operating Condition

-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)

Communication

Up the coax, Protocol: HIKVISION-C (TVI output)

Language

English, Chinese

Power Supply 12 VDC ± 25%

Consumption Max. 4.5 W

IR Range Up to 20 m

Approval Protection

1P67
