Camera

Image Sensor: 2.0 megapixel progressive scan CMOS

Signal System: PAL/NTSC

Min. Illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR

Shutter Time: PAL: 1/25 s to 1/50, 000 s

NTSC: 1/30 s to 1/50, 000 s

Lens: 2.8 mm, 3.6 mm fixed focal lens

Day& Night: IR cut filter

Horizontal Resolution: 1920 (H) × 1080 (V)

Synchronization: Internal Synchronization

Lens

Horizontal Field of View: 103° (2.8 mm), 82.2° (3.6 mm)

Menu

White Light: Alarm/Off

D/N Mode: Auto/Color/BW (Black and White)

White Balance: ATW/MANUAL

AGC: Yes

Language: English/Chinese

Function: Brightness, Contrast, Sharpness, Saturation, DNR, Mirror

Interface

Video Out: 1 HD analog output

General

Visual Alarm: Yes

PIR Range: Angle: 110°, Range:11 m

Material: Enclosure: Plastic

Main body: Metal

Ingress Protection: IP67

Power Supply: 12 VDC±25%

IR Range: Up to 20m

Communication : Up the coax, Protocol: HIKVISION-C (TVI output)

Dimension: Ø 109.8 mm × 89.75 mm (Ø 4.32" × 3.53" )

Weight: Approx. 310 g (0.68 lb.)
