Camera

Image Sensor 1/3 "CMOS

Effective Pixels 2688 (H) x 1520 (V)

Scanning system

Progressive

Electronic shutter

1 / 100,000c

Sensitivity

0.01 Lux / F2.0 (color), 0.001 Suite / F2.0 (night)

S / N Ratio

More than 65 dB

Illumination Illumination no

Backlight control no

Ic diodes no

Lens Type of lens

Fixed lens / fixed aperture

Mounting type

built-in

Focal length

1.18 mm

Viewing Angle 180 °

Appperture 2.0

Focusing distance 100 mm

Rotation during installation

Rotate / Tilt / Rotate

Rotate: -;   Inclination: - ; Rotation: -;

Video

Resolution

4Mp (2560x1440)

Frame frequency

4Mp / 1080p - 25 frames / second

Video output

1 channel BNC - HDCVI high definition / 1-channel CVBS analog output (simultaneously)

Day Night

Auto (software) / manually

OSD menu

Multilingual

BLC mode

BLC / HLC / WDR

WDR

120dB

Gain control

AGC

Noise Reduction

2D / 3D

White balance

Auto / Manual

Smart IR no

General information

Power supply DC12V ± 25%

Power Consumption

Max. 2.2W

Work environment

-30 ° C ~ + 60 ° C / Less than 95%

Degree of protection

IK10

Dimensions (Diameter × Height)

f110x56 mm

The weight

410g

Material

Aluminum
