Camera

Lens Angle of view: 29.3°-92°

Lens Mount φ14

Day & Night ICR

Synchronization Internal synchronization

Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360°

Effective Pixels 1280(H)*960(V)

S/N Ratio ＞62dB

Image Sensor 1.3MP CMOS Image Sensor

Signal System PAL/NTSC

Frame Rate 720p@25fps/720p@30fps

Min. Illumination 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR

Shutter Time 1/25(1/30)s to 1/50,000s

Interface Video Output

1 Analog HD output

General Operating Condition

-40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

Power Supply 12 VDC±15%

Power Consumption Max. 4W

Protection Level IP66

IR Range Up to 40m

Dimensions 92 × 84.8 × 269.6mm(3.62” × 3.34” × 10.6”)

Weight 1000 g
