Image Sensor: 1MP CMOS Image Sensor

Signal System: PAL/NTSC

Effective Pixels: 1296(H)x732(V)

Min. Illumination: 0.1 Lux @(F1.2,AGC ON), 0 Lux with IR

Shutter Time: 1/25(1/30) s to 1/50,000 s

Lens: 3.6mm (2.8mm, 6mm optional), Angle of View: 70.9°(3.6mm), 92°(2.8mm), 56.7°(6mm)

Lens Mount: M12

Adjustment Range: Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360°

Day& Night: IR cut filter with auto switch

Video Frame Rate: 720p@25fps/720p@30fps

HD Video Output: 1 Analog HD output

Synchronization: Internal Synchronization

S/N Ratio: More than 62 dB

General

Operating Conditions: -40 °C - 60 °C (-40 °F - 140 °F)

Humidity 90% or less (non-condensing)

Power Supply: 12 VDC±15%

Power Consumption: Max. 4W

Weather Proof: IP66

IR Range: Up to 20m

Dimension: Φ70×149.5 mm (Φ2.76” ×5.89”)

Weight: 400 g
