Camera

Image Sensor 3MP CMOS Image Sensor

Effective Pixels 2052(H)*1536(V)

Min. illumination 0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR

Shutter Time 1/25(1/30)s to 1/50,000s

Lens

2.8mm, 3.6mm, 6mm optional

Angle of View: 84°(2.8mm), 67.8°(3.6mm), 44.6°(6mm)

Lens Mount M12

Day & Night ICR

Angle Adjustment Pan: 0°- 360°; Tilt:0°- 90°; Rotate: 0°- 360°

Synchronization Internal Synchronization

Video Frame Rate 1920×1536@18fps

HD Video Output 1 Analog HD output

S/N Ratio ＞62dB

Menu

AGC Support

D/N Mode Color/BW/SMART

White Balance ATW/ MWB

BLC Support

Functions Digital noise reduction, Mirror, SMART IR

General

Operating Conditions -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

Power Supply 12 VDC±15%

Power Consumption Max. 5W

Protection Level IP66

IR Range Up to 20m

Communication Up the coax, Protocol: HIKVISION-C (TVI output)

Dimensions 58.5mm×55.5mm×153.6mm (2.30”×2.19”×6.05”)

Weight Approx. 370g (0.82lb)
