Camera

Lens

Field of view: 70.9°(3.6 mm), 92°(2.8 mm), 56.7°(6 mm)

Lens Mount

M12

Day & Night

ICR

Synchronization

Internal synchronization

Angle Adjustment

Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°

Effective Pixels

1296 (H) × 732 (V)

S/N Ratio

>62 dB

Image Sensor

1 MP CMOS image sensor

Signal System

PAL/NTSC

Frame Rate

720p@25fps/720p@30fps

Min. Illumination

0.01 Lux@(F1.2, AGC ON), 0 Lux with IR

Shutter Time

1/25 (1/30) s to 1/50,000 s

Interface

Video Output

1 analog HD output

General

Operating Condition

-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)

Power Supply

12 V DC±15%

Power Consumption

Max. 4 W

IR Range

Up to 20 m

Dimensions

Φ 89.9 mm × 70.1 mm (3.54" × 2.76")

Weight

250 g (0.55 lb.)
