Camera

Image Sensor 5 megapixel progressive scan CMOS

Max. Resolution 2560 (H) × 1944 (V)

Min. Illumination Color: 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter Time PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s

Day & Night IR cut filter

Angle Adjustment Pan: 0° to 360°; Tilt: 0° to 90°; Rotate: 0° to 360°

Signal System PAL/NTSC

Lens

Lens Type 2.7 mm to 13.5 mm motorized varifocal lens

Focal Length & FOV 92.3° to 29.3°

Lens Mount Φ 14


Image Settings Brightness, Sharpness, 3D DNR, Mirror, Smart IR

Frame Rate TVI: 2 MP@25fps, 2 MP@30fps, 4 MP@25fps, 4 MP@30fps, 5 MP@20fps,AHD: 4 MP@25fps, 4 MP@30fps, 5 MP@20fps,CVI: 4 MP@25fps, 4 MP@30fps,CVBS: PAL, NTSC

Day/Night Mode Auto/Color/BW (Black and White)

Wide Dynamic Range (WDR) ≥ 130 dB

Image Enhancement BLC

Privacy Mask 4 programmable privacy masks

Noise Reduction Level 1 to 9

White Balance Auto/Manual

AGC Yes

Interface Video Output Switchable TVI/AHD/CVI/CVBS

Event Motion Detection 4 programmable areas

General

Material Metal

Dimension 84.5 mm × 92 mm × 255.1 mm (3.33" × 3.62" × 10")

Weight Approx. 930 g (2.05 lb.)

Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)

Communication Up the coax, Protocol: HIKVISION-C (TVI output)

Language English

Power Supply -A: 9.6 VDC to 14.4 VDC; 19.2 VAC to 28.8 VAC

Consumption -A: Max. 10.5 W

IR Range Up to 80 m Approval

Protection IP67
