Recording

Video Compression H.264+/H.264

Encoding Resolution When 1080p lite mode not enabled: 720p/WD1/4CIF/VGA/CIF When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA/CIF

Frame Rate: Main stream: When 1080p lite mode enabled: 1080p lite/HD 720p lite/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N) When 1080p lite mode not enabled: For 720p stream access: 720p/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N) For SD stream access: WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) Sub-stream: CIF/QVGA/QCIF@25fps (P)/30fps (N)

Video Bit Rate 32 Kbps to 4 Mbps

Dual Stream Support

Stream Type Video, Video & Audio

Audio Compression G.711u

Audio Bit Rate 64 Kbps

Video And Audio

IP Video Input Up to 8-ch Up to 960p resolution Support H.264+/H.264 IP cameras

Analog Video Input 8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

Turbo HD Input 1080p25, 1080p30, 720p25, 720p30

AHD Input 1080p25, 1080p30, 720p25, 720p30

HDCVI Input 1080p25, 1080p30, 720p25, 720p30

CVBS Input Support

Audio Input 1-ch, RCA (2.0 Vp-p, 1 KΩ)

Audio Output 1-ch, RCA (Linear, 1 KΩ)

Two-Way Audio Reuse the first audio input

Synchronous Playback 8-ch

VGA/HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Network

Remote Connections 128

Network Protocols TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Network Interface 1, RJ45 10M/100M self-adaptive Ethernet interface

Auxiliary Interface

SATA 1 SATA interface

Capacity Up to 6 TB capacity for each disk

Alarm In/Out N/A

USB Interface Rear panel: 2 × USB 2.0

General

Power Supply 12 VDC

Consumption (Without HDD) ≤ 12 W

Working Temperature -10 °C to 55 °C (14 °F to +31 °F)

Working Humidity 10% to 90%

Dimensions (W × D × H) 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)

Weights (Without HDD) ≤ 0.8 kg (1.8 lb)
