Camera

Image Sensor: 5MP CMOS Image Sensor

Effective Pixels: 2560 (H) × 1944 (V)

Shutter Time: 1/25(1/30) s to 1/50,000 s

Lens Mount: M12

Adjustment Range: Pan: 0° to 360°; Tilt:0° to 180°; Rotate: 0° to 360°

Day& Night: IR cut filter with auto switch

Video Frame Rate: 2560 × 1944 @ 20fps

HD Video Output: 1 Analog HD output

Synchronization: Internal Synchronization

Menu

D/N Mode: Auto / Color / B/W

Auto White Balance: Auto/MWB

BLC: Support

Language: English

General

Operating Conditions: -40 °C - 60 °C (-40 °F - 140 °F)

Humidity 90% or less (non-condensing)

Power Supply: 12 VDC±25%

Weather Proof: IP67

IR Range: Up to 20m

Communication : Up the coax

Protocol: HIKVISION-C(Coaxitron)

Dimension: 58 mm × 61 mm × 163 mm (2.28" × 2.40" × 6.42")

Weight: Approx. 350 g (0.77 lb.)
